phyCORE-AM64x Software Release (BSP-Yocto-Ampliphy-AM64x-PD23.2.0)


Software Release Name: BSP-Yocto-Ampliphy-AM64x-PD23.2.0

Release Date: September 29, 2023Release Highlights:

Yocto

  • MACHINE= phyboard-electra-am64xx-2 for TI’s High Security-Field Securable (HS-FS) SoCs.
    • HS-FS variant phyCORE-AM64x SOMs are now the default SOM configuration shipping in Development kits.
  • UART boot source now available.
  • Inline ECC support is now available and enabled by default.
  • Virtualization support with Podman/Docker

Linux Kernel

  • TSN support for Ethernet.
  • New device tree overlay references for disabling optional population options of the SOM.
  • Watchdog support
  • GPIO FAN with pre-set thermal zone
  • ADC channels are configured correctly
  • RPMSG reserved memory regions enabled by default (previously enabled by device tree overlay)

U-Boot Bootloader

  • EEPROM Hardware introspection enabled for identifying Ethernet PHY, SPI-NOR Flash, and RTC population options
  • USB Host support



View Full Release Notes Here: http://docs.phytec/phycore-am64x/software/releasenotes/index.html

Repo Links

U-Boot: https://github.com/phytec/u-boot-phytec-ti/tree/v2023.04_09.00.00.007-phy3 (tag: v2023.04_09.00.00.007-phy4)

Linux: https://github.com/phytec/linux-phytec-ti/tree/v6.1.33-phy3 (tag: v6.1.33-phy3)

Yocto: https://git.phytec.de/meta-phytec/tag/?h=BSP-Yocto-Ampliphy-AM64x-PD23.2.0 (tag: BSP-Yocto-Ampliphy-AM64x-PD23.2.0)

To evaluate the phyCORE-AM64x purchase a development kit or get in touch with the PHYTEC Sales Team today!
